Coal, coke and solid biomass fuel ash and volatile test is mainly applied in the sectors of electricity, coal, metallurgy, petrochemical, environmental protection, cement, paper, geological exploration, scientific research institutions. GB/T212-2008 This product complies with GB/T212-2008 "method of analysis of coal"
Conformance with Standards
ISO1171 Solid mineral fuels – Determination of ash ISO562 Hard coal and coke - Determination of volatile matter ASTM D3174-04 Standard Test Method for Ash in the Analysis Sample of Coal and Coke ASTM D3175-07 Standard Test Method for Volatile Matter in the Analysis Sample of Coal and Coke GB/T212-2008 Standard Test Method for Proximate Analysis of Coal
Specification
Temperature range: room temperature - 1000 ° C
Temperature control accuracy: ± 2.5 ℃
Temperature Resolution: 1 ° C
Maximum power: 3.5kW
Power Requirement: 220V(-15%-10%),50/60Hz
Furnace size: 298 * 203 * 121
Dimension (mm): 435*591*520
Highlights
1.Humanistic Design & High Precision * Choosing classic fast ash test, the operator only need to load sample onto the autoloader. Then sample will
be sent to the furnace and be tested automatically. When test finishes , samples will be sent out of the
furnace automatically The operator is free from heat radiation during the test.
* Sample sending is fully automatically controlled to avoid error from manual operation.
*Timing and Countdown are available for observation of time and temperature.
* Microprocessor controlled and large LCD screen.
2.Powerful & Stable Performance * It support slow ash , fast ash I(classic fast ash),fast ash II ,Volatile matter, and general
test methods. Constant thermostatic period, and heating rate can be set up at the general
testing mode.
* With classic fast ash test mode , the operate can choose manual or automatic sample
preparation with the spin button . Time of sample introduction can be modified based
on user’s needs.
* The instrument has alarming and power-off protection function against thermocouple
counter-connection, thermocouple disconnection and over-temperature & heating power
open circuit . And it has hibernating function which extend service time of furnace.
